Features and characteristics
1.Adopting a unique fast response electromagnetic force balance sensor, the measurement accuracy and linearity have been improved;
2.The instrument calibration only needs to calibrate one point, solving the problem of the previous generation of sensors requiring multi-point calibration. Eliminating the need for zero adjustment potentiometers and full-scale potentiometers;
3.Real time display of equivalent tension value and current weight (can be used as an electronic balance for weighing);
4.Integrated temperature detection circuit, automatic temperature compensation for test results;
5.240 × 128 dot matrix LCD display screen, no labeled buttons, with screen protection function;
Historical records with time stamps can store up to 255 records;
6.Built in high-speed thermal micro printer, with beautiful and fast printing, and offline printing function;
7.Equipped with a standard RC232 interface, it can be connected to a computer for easy processing of experimental data (optional);
Technical indicators and usage conditions
Name indicator
Measurement range 0-200mN
Accuracy 0.1% reading ± 0.1 mN/m
Sensitivity 0.1 mN/m
Resolution 0.1 mN/m
Power supply voltage AC 220 V 10%
Power frequency 50 Hz 2%
Power ≤ 20W
Suitable temperature range: 10-40 ℃
Suitable for humidity<85% RH
Width x Height x Depth 200mm * 330mm * 300mm
Net weight~5kg
