Main functions and features
1.4.3-inch color touch screen with a resolution of 480 × 272, featuring beautiful and user-friendly human-computer interaction.
2. Adopting a 32-bit microprocessor as the main control core and a new generation intelligent operating system.
3. PID temperature control, precise control of constant temperature funnel temperature.
4. Adopting a built-in oil-free and maintenance free vacuum pump, with program control for pressure reduction and filtration.
5. The uniquely designed vacuum pump structure ensures that even if oil samples are sucked into the vacuum pump, the instrument will not be damaged, reducing accidental losses.
6. Compact structure, occupying only 15% more area than A4 paper.
technical indicators
1. Method used: GB/T 511-2010 "Petroleum and petroleum products and additives - Determination of mechanical impurities"
2. Display: 4.3-inch LCD display with a resolution of 480 × 272
3. Temperature control range: Room temperature to 99 ℃
4. Temperature control accuracy: ± 0.5 ℃
5. Resolution: 0.1 ℃
6. Rated power: 240 W
7. Dimensions: 240 × 300 × 400 (in millimeters, excluding foot pads)
8. Weight: 6 kg
Usage conditions
1. Environmental temperature: 5 ℃~40 ℃
2. Relative humidity:<80%
3. Input power supply: AC220V ± 10V 50Hz
