Key Features：
Easy connection, automatic measurement and built-in data storage function;
Dual display mode with digital readings and analog progress bar for easy observation;
Wide measuring range: 0.1 MΩ ~ 200 GΩ, test voltage up to 2.5 kV, output short-circuit current ≥25 mA;
Wide AC power supply voltage range, suitable for field operation;
Stable operation under ambient temperature from -10 ℃ to 40 ℃, adaptable to various test environments.
Technical Specifications & Operating Conditions
|
Model |
HYDA |
|
Accuracy |
±(5% + 5 digits) |
|
Measuring Range |
0.1 MΩ ~ 200 GΩ |
|
Display Mode |
Dual display of digital readout and analog progress bar |
|
Temperature Measurement |
-25 ℃ ~ 125 ℃ |
|
Test Voltage |
2.5 kV |
|
Short-circuit Current |
≥25 mA |
|
Measuring Time |
1~ 10 min |
|
Power Supply |
180 ~ 270 VAC, 50 Hz/60 Hz ±1% |
|
Ambient Temperature |
-10 ~ 40 ℃ |
|
Relative Humidity |
20 ~ 80% |
